| ez-CGER VM4 | |||
| Overview | Tech Specs | ||
| Find a reseller | Download | ||
| Quote | |||
| Audio Video Input | Video Input : SD/HD-SDI (BNC 75Ohm) x 4 Fill & Key Input : USB 3.0 x 1 |
| Output | Video Output: HD -SDI (BNC 75 Ohm) x1 Multiview Output : USB 3.0 x 1, (1920x270P @30/25, 1280x180p @60/50) |
| USB Devices | USB 3.0 Video Streamer Device : Fill& Key Input, Multiview Output USB 2.0 USB to Serial (Com Port) Device : Control USB 2.0 USB to SPI Device : Firmware Update |
| Software |
OS : Windows7, Windows8, Windows10 CPU: Intel i7 4th Generation or above (Desktop) Intel i7-7700HQ or above (Laptop) RAM: 8GB VGA: GeForce GTX 1050 USB 3.0 Host Controller |
| Internal Video Processing | 4:2:2 10 bit |
| Input Resolution Supported | 1920 x 1080i @59.94/60/50 1280 x 720p @59.94/60/50 |
| Management | Large "L"logo LED @ front : easy to identify device status USB @ Rear : easy to use GUI application, Firmware update |
| Physical | Dimension : 44(H) x 483(W) x240(D) (excluding connectors) Operation Temperature : 0-40 C Weight : 3.1 Kg Power Consumption : 30W (max.) |
